Technical Specifications

Power:

22kW/11kW
Current:

16A， 32A （EU） -240V
Voltage:

Three phase, 323-437V AC
Frequency:

47-63Hz
Operating Temperature:

-40℃～+55℃
Storage Temperature:

-40℃～+85℃
Relative Humidity:

5-95%, without condensation
Ingress Protection:

IP66
Impact Protection:

IK10
Residual Current Protection Rated Operating Current:

30mA, +DC 6mA
Residual Current Protection Rated Action Time:

≤0.1 s
Connector Power Line Contact:

AC400V, 35A
Connector Operating Life:

≥ 10000 times
Altitude:

≤ 2000m
