J Line_DC Charging_Product

Technical Specifications

Power

30、40kW
60kW
Input Voltage

Three phase，400VAC±15% TN-S
Frequency

45~65 Hz
Max Output Current

CCS2、GBT、CHAdeMO: 125A
CCS2: 200ACHAdeMO: 125A
Operating Temperature

-30℃～+50℃
Relative Humidity

5-95%, without condensation
Ingress Protection

IP54
Cooling Method

Forced Air-Cooling
Network Connection

4G/Ethernet
Communication Protocols

OCPP1.6J or OCPP2.0.1
Screen

8"LCD Touch Screen
Cable length

5m or 7m（Optional other lengths）
Dimensions（W*D*H）

690*275*1686mm
690*357*1686mm
Packing Size（W*D*H）

Charger：1250*1024*852mm
Column：740*680*1978mm
Charger：1250*1024*742mm
Column：740*680*1878mm
Weight（Including outer packaging）

Charger: 180kg, Column: 101kg
Charger: 216.5kg, Column: 107kg
Payment

APP/RFID/POS(Optional)
Language

Support customizing languages
Certificate

NTC CE
TUV CE
